Overall Length
1190 mm / 46.9"
Overall Width
670 mm / 26.4"
Overall Height
1265 mm / 49.8"
Weight W / Batteries
140 kgs / 309 lbs
Max. Speed
8 kmph / 5 mph
Weight Capacity
136 kgs / 300 lbs
Ground Clearance
45 mm / 1.8"
Curb Climbable
35 mm / 1.4"
Turning Radius
1070 mm / 42.1"
Seat Type
Foam Padded Breathable Ballistic Nylon Back Rest W/ Headrest, Back Angle Adjustment & Seat Belt
Seat Back Angle
100 ~ 170 degree
Tilting Angle
0 ~ 70 degree
Elevating Height
0 ~ 190 mm / 0 ~ 7.5"
Seat Width
457.2 mm / 18"
Drive Train
2 Motor, Rear-wheel Drive
Motor Size
420W, 4600 r.p.m.
Battery Size
(2) 12V. 75Ah
Weight of Battery
55 kgs / 121 lbs
Travel Range
48 km / 29.8 mi
Battery Charger
8A Off Board
*Subject to change without notice.
.jpg "Rehab Chair - Elevating & Bed Type")
.jpg "Rehab Chair - Elevating & Bed Type")
.jpg "Rehab Chair - Elevating & Bed Type")
Maximum Speed : 8 kmph / 5 mph
Capacity : 136 kgs / 300 lbs
