Overall Length
1080 mm / 42.5"
Overall Width
670 mm / 26.4"
Overall Height
1030 mm / 40.6"
Weight W / Batteries
116 kgs / 256 lbs
Max. Speed
8 kmph / 5 mph
Weight Capacity
162 kgs / 357 lbs
Ground Clearance
65 mm / 2.6"
Curb Climbable
35 mm / 1.4"
Turning Radius
920 mm / 36.2"
Seat Type
Padded Breathable Ballistic Nylon Back Rest W/ Adjustable Back Angle & Seat Belt
Seat Back Angle
100 ~ 140 degree
Seat Back Height
520 mm / 20.5"
Tilting Angle
0 ~ 18 degree
Seat Width
406.4 mm / 16" | 457.2 mm / 18"
Drive Train
2 Motor, Rear-wheel Drive
Motor Size
420W, 4600 r.p.m.
Battery Size
(2) 12V. 75Ah
Weight of Battery
55 kgs / 121 lbs
Travel Range
48 km / 29.8 mi
Battery Charger
8A Off Board
*Subject to change without notice.
.jpg "Rehab Chair - Tilting")
.jpg "Rehab Chair - Tilting")
.jpg "Rehab Chair - Tilting")
Maximum Speed : 8 kmph / 5 mph
Capacity : 162 kgs / 357 lbs
